Solcore - K5 (F1D) - Instantaneous Water Heater (inverter)

The Solcore K5 (F1D) is a compact, wall-mounted instantaneous electric water heater with inverter technology that keeps the water temperature stable and uses only the power it needs. Choose 3.5, 4.5 or 5.5 kW to suit your electrical supply, and set the temperature from 25°C to 55°C on the digital LED display with touch controls. A cast aluminium heating element, continuous self-diagnosis and double leakage protection (RCD 28 mA plus earth leakage protection wall) give reliable, safe operation. Measuring just 30.5 × 13 × 7 cm, it can supply several outlets as a main or supplementary heater, and can be connected in series with a solar water heater.

Rated Voltage: 230V
Rated Power: 5500 Watt
Rated Current: 40A
Minimum Pressure: 0,20 Atm

Price on request

In Stock

request_quote Request Quote / Reserve Stock download Files (2)

support_agent Need sizing advice? Call our Paphos engineering desk: +357 26 819 636

Engineering datasheet

Technical Parameters & Installation

Parameter	Value
Rated Voltage	230V
Rated Power	5500 Watt
Rated Current	40A
Minimum Pressure	0,20 Atm
Minimum Flow	2,5 l/min
Rated Pressure	6,0 Atm (up to 10 Atm Maximum*)
Rated Current	24A

Single-phase (Digital – Inverter)
Quick and easy installation
Cast aluminum 6th generation technology heating elements (0% scale)
Dynamic Temperature Control “DTC” from 25°C to 55°C
Multi-segment LED type display & touch control panel
Adjustable power range from 3.5kW, 4.5kW and 5.5kW (3 in 1 smart power)
Hybrid connection ready
Multiple safeguards
Continuous self-check for proper operation and faults
Dual electric leakage Protection (RCD, ELPW)
Modern design
